Technical Features
| CPU | i.MX 93 applications processor MIMX9352CVVXMAB, Dual core, 1.7GHz, NPU, -40°C÷105°C/td> |
|---|---|
| Chipset | |
| RAM | 2GB LPDDR4 Memory Down |
| LAN | 2 x GbE (RJ-45) |
| I/O | 4 x USB 2.0; 1 x Micro USB 2.0 (OTG); 1 x RS485 (2-wire); 1 x RS232, 1x RS232/422/485 on 2×6 header; 1 x HDMI; 1 x LVDS LCD Panel connector (Default: 12V/Opt.: 5V); 1 x LCD Backlight Power (Default: 5V/Opt.: 3.3V); 1 x uSD card; 1 x 8-bit DIO; 1 x I2 C / Touch; 1 x CAN bus 2.0b; 1 x MIPI-CSI for 2-lanes camera, reference to RPI-CAM-MIPI Camera adapter (AR0144 Sensor); 1 x SPI, 1 x Front Panel, 1 x UART debug |
| Storage | 1 x eMMC 5.1 with default 16GB (up to 64GB) |
| Expansion | 1 x M.2 B key 3042 (USB 2.0); 1 x Nano SIM slot |
| Operative range | -40° ÷ 85° C |
| Power | Wide Range 9÷36VDC |
| Notes | CE, FCC Class B, RoHS, UKCA |
