Technical Features
| CPU | 3rd Gen Intel® Xeon® Scalable processors |
|---|---|
| Chipset | Intel® C621A |
| RAM | 32 DIMM Slots, Up to 8TB: 32x 256 GB DRAM; Up to 12TB: 16x 512 GB PMem and 16x 256 GB DRAM, 3200/2933/2666 ECC DDR4 LRDIMM;RDIMM |
| LAN | 1 X RJ45 Dedicated BMC LAN port |
| I/O | 2 X USB 3.0 port(s) (2 rear); 1 VGA port(s); 1 X COM Port(s) (1 rear) |
| Storage | 12 X 3.5″ hot-swap hybrid NVMe/SATA/SAS drive bays |
| Expansion | 6 X PCI-E 4.0 x8; 2 X PCIe 4.0 x16 |
| Operative range | 10°C ~ 35°C |
| Power | 1200W redundant Titanium level power supplies; |
| Notes | – |
