Technical Features
| CPU | T5000: 14-core Arm® Neoverse™ V3AE 64-bit CPU |
|---|---|
| GPU | T5000: 2,650-core NVIDIA Blackwell™ GPU with 5th GEN 96 Tensor Cores |
| Chipset | |
| RAM | 128 GB 256-bit LPDDR5X DRAM |
| LAN |
LAN 1 to LAN 2 2 x 2.5GigE LAN RJ45 Connector by Intel i226 LAN 3 to LAN 4 EAC-7200/7400: 2 x 10GigE LAN RJ45 Connector by Marvell x3610 PoE+ LAN 3 to LAN 6 EAC-7300: 2 x IEEE 802.3at (25.5W/48V) 1GigE PoE+ RJ45 LAN LAN 5 to LAN 6 EAC-7400: 2 x IEEE 802.3at (25.5W/48V) 10GigE PoE+ RJ45 LAN |
| I/O | 4 x USB 3.1 Type-A; 1 x USB Type-C for console debug port; 1 x USB Type-C for OS flash port; 2 x COM RS-232/422/485; 4 x Isolated CAN Bus support Flexible Data-rate; 16 x Isolated DIO (8 DI, 8 DO); 2 x Nano SIM Card Socket; 8 x Antenna for 5G/WiFi/4G/LTE/GPRS/UMTS |
| Storage | 1 x M.2 Key M Socket (2280, PCIe x4) |
| Expansion | 1 x M.2 Key B Socket for dual SIM (3042/3052, USB 3.0); 1 x M.2 Key B Socket (3042/3052/2280, PCIe x2); 1 x M.2 Key E Socket (2230/3042, PCIe x1/USB 2.0/UART3)) |
| Operative range | 77W TDP Mode Fanless: -20°C ÷ 45°C 77W TDP Mode Fan: -20°C ÷ 70°C 130W TDP Mode Fan: -20°C ÷ 50°C |
| Power | DC 9V ÷ 50V wide range power input, 16-mode Software Ignition Control |
| Notes | EAC-7100: 8 x Fakra-Z connectors for GMSL 1/2 automotive cameras EAC-7200: 4 x 4 mini Fakra connectors for GMSL 1/2 automotive cameras |
