General Features
Intel Alder Lake-N processor
Dual Battery with Hot Swappable Design
Onboard 8GB/16GB LPDDR5
Total IP65 Design
1 x USB 3.0 type A
1 x USB type-C (with display port & power delivery)
1 x USB 3.0 type A (optional)
Technical Features
| CPU | Intel Alder Lake-N Processor N50; Intel Alder Lake-N Processor N200 | System Chipset | Intel ® SoC |
| Memory | LPDDR5 8GB or 16GB |
| Storage | 1 x M.2 Nvme SSD (up to 1TB) |
| Display | 10.1″ FHD display (1920 x 1200 resolution / 450 or 1000 nits / 30,000 hrs) |
| Max resolution 1920 x 1200 | |
| 450 or 1000 nits | |
| Touch screen | Optical clear Adhesive with Anti-fingerprint / rugged corning; gorilla glass P-Cap touch |
| RF | 802.11 ax, Bluetooth®; 4G/5G with GNSS |
| Data Collection | Front camera 2M pixels (optional, Windows hello camera); Rear camera 8M pixels; 3D camera for dimension measurement application (optional) |
| Control Button | 6 x Buttons (Windows, power, function key 1, function key 2, volume up, volume down) (programmable) |
| I/O Interface | 1 x USB 3.0 type A; 1 x USB type-C (with display port & power delivery); 1 x USB 3.0 type A (optional); 1 x Headset (headphone out / mic-in combo); 1 x DC 19V jack; 1 x Dual-Nano-SIM 4G LTE / 5G; Expansion Slot 1 for Smart Card Reader, Fingerprint; 3D Dimension Camera Expansion Slot 2 for 2D Barcode, COM Port, USB 3.0 Type-A, SD Card, LAN Port |
| Battery | 2 x Li-Ion battery (11.1V, typical 2100mAh) |
| Power | DC jack 19V; USB Type-C power delivery 20V |
| Dimensions and Weight | 275 x 194.5 x 21 mm |
| 1.08 kg (tablet only) | |
| Certification | CE, FCC |
| Operating System | Windows 11 IoT Enterprise |
| Environment | Operating temperature -10°C ÷ +50°C |
| Storage temperature -20°C ÷ +60°C | |
| Operation humidity 10%÷90%; Storage humidity 10%÷95% |
