Technical Features
| CPU | AMD Ryzen 9 PRO 7945; AMD Ryzen 7 PRO 7745; AMD Ryzen 5 PRO 7645 |
|---|---|
| Chipset | AMD B650 |
| RAM | Four 288-pin UDIMM up to 128GB (ECC/Non-ECC); Dual Channel DDR5 5200 MHz |
| LAN | 2 x Intel® I226V – 2 x 2.5GbE (RJ-45) |
| I/O | 6 x USB 3.2 Gen 2; 2 x USB 2.0; 4 x USB 2.0 (colay vertical Type A); 2 x USB 3.2 Gen1; 1 x RS-232/422/485; 3 x RS232; 1 x VGA resolution up to 1920×1200 @ 60Hz; 1 x DP++ resolution up to 3840×2160 @ 60Hz; 1 x HDMI 2.0 resolution up to 4096×2160 @ 60Hz; 1 x 8-bit DIO; 1 x SMBus/ I2C |
| Storage | 4 x SATA 3.0 RAID 0/1/5/10 |
| Expansion | 2 x PCIe x16 (Gen 4, x16 or x8+x8); 2 x PCIe x4 (Gen 4); 1 x M.2 2230 E key; 1 x M.2 2242/2260/2280 M key |
| Operative range | -5° ÷ 65° C |
| Power | ATX |
| Notes | CE, FCC Class B, RoHS |
