Technical Features
| CPU | Intel® Atom x7000RE series processors (Code Name: Amston Lake); Intel® Atom Processor x7211RE, 2 Cores, 1.0~3.2 GHz, 6 W; Intel® Atom Processor x7433RE, 4 Cores, 1.5~3.4 GHz, 9 W; Intel® Atom Processor x7835RE, 8 Cores, 1.3~3.6 GHz, 12 W |
|---|---|
| Chipset | – |
| RAM | One 260-pin SODIMM up to 16GB Single Channel DDR5 4800MHz |
| LAN | 2 x Intel® i210IT(10/100/1000Mbps) |
| I/O | 2 x USB 2.0 (1.0mm pitch); 4 x USB 3.2; 2 x RS-232/422/485 (1.0mm pitch); 2 x RS-232 (1.0mm pitch); 1 x HDMI resolution up to 4096×2160 @ 24Hz; 1 x LVDS dual channel 24-bit, resolution up to 1920×1200 @ 60Hz; 1 x 8-bit DIO |
| Storage | 1 x SATA 3.0 (up to 6Gb/s); 1 x SATA Power |
| Expansion | 1 x M.2 M key 2242 (PCIe Gen3 x2/SATA3.0); 1 x M.2 B key 2242 (PCIe x1, USB3/2), 1 x SIM slot; 1 x M.2 E key 2230 (USB/PCIe x1) |
| Operative range | -40° ÷ 85° C |
| Power | 9÷36V DC |
| Notes | CE, FCC Class B, RoHS, UKCA |
