Technical Features
| CPU | Intel® Core™ Ultra LGA 1851 Socket Processors, support up to TDP; Intel® Core™ Ultra 9 285 (24 Cores, 36M Cache, up to 5.6 GHz); 65W; Intel® Core™ Ultra 9 285T (24 Cores, 36M Cache, up to 5.4 GHz); 35W; Intel® Core™ Ultra 7 265 (20 Cores, 30M Cache, up to 5.3 GHz); 65W; Intel® Core™ Ultra 7 265T (20 Cores, 30M Cache, up to 5.3 GHz); 35W; Intel® Core™ Ultra 5 245 (14 Cores, 24M Cache, up to 5.1 GHz); 65W; Intel® Core™ Ultra 5 245T (14 Cores, 24M Cache, up to 5.1 GHz); 35W; Intel® Core™ Ultra 5 225 (10 Cores, 20M Cache, up to 4.9 GHz); 65W; Intel® Core™ Ultra 5 225T (10 Cores, 20M Cache, up to 4.9 GHz); 35W |
|---|---|
| Chipset | Intel® W880 Chipset Intel® e Q870 Chipset |
| RAM | 4 x 288-pin UDIMM up to 192GB (ECC/Non-ECC) Dual Channel DDR5 up to 5600 MHz (Intel® W880 Chipset); 4 x 288-pin UDIMM up to 192GB (Non-ECC) Dual Channel DDR5 up to 5600 MHz (Intel® Q870 Chipset) |
| LAN | 1 x Intel® I226-LM; 1 x Intel® I210-AT (co-lay I226-V); 2 x Intel® I226-V (only for ARS630-W880) |
| I/O | 4 x USB 3.2 Gen 2; 6 x USB 3.2 Gen 1; 1 x USB 2.0 Vertical Type A; 2 x USB 2.0 Pin Header (2.54mm pitch); 2 x RS-232/422/485; 4 x RS-232; 1 x VGA resolution up to 1920×1200 @ 60Hz; 2 x DP++ resolution up to 4096×2304 @ 60Hz; 1 x HDMI 2.0a VGA: resolution up to 4096×2160 @ 24H; 4-IN / 8-OUT DIO; 1 x SMBus |
| Storage | 4 x SATA 3.0 (up to 6Gb/s); RAID 0/1/5/10 |
| Expansion | 2 x PCIe x16 (Gen 5, 16 or 8+8); 1 x PCIe x4 (Gen 5, share M.2 M-key, function selected by BIOS.); 3 x PCIe x4 (Gen 4); 1 x PCI; 1 x M.2 M key (opt. share PCIe x4 Gen5 slot #2, function selected by BIOS.); 1 x M.2 M key (PCIe x4 Gen4 NVMe, SATA); 1 x M.2 A key for M2-OOB; 1 x M.2 E key |
| Operative range | -5°C – 65°C |
| Power | ATX |
| Notes | CE, FCC Class B, RoHS, UKCA |
