General Features
CPU Intel® Xeon® E3-1505M v5/Core™ i7-6820EQ Processor (Skylake-H)
Chipset Intel® CM236
RAM 2 DDR4 2133MHz SO-DIMM, up to 32GB
LAN 10 Independent GigE LAN with 4 IEEE 802.3at PoE+ and 4 IEEE 802.3af PoE
I/O 32 Isolated DIO, 6 USB 3.0, 4 COM RS-232/422/485 (ESD 8KV)
Storage 2 Front-access 2.5″ SSD Tray
Expansion 2 Mini PCIe, SUMIT A, B
Operative range -20°C to 60°C
Power 10V to 36V DC-in with 80V Surge Protection, Configurable Ignition Power Control
