General Features
CPU Quad Core Intel® Xeon®/Core™ i7/i5/i3 Processor (Skylake-S/Kaby Lake-S)
Chipset Intel® C236
RAM 2 DDR4 2133MHz SO-DIMM, up to 32GB (ECC/Non-ECC)
LAN 10 Independent GigE LAN with 8 IEEE 802.3at PoE+, 4-port X-coded M12
I/O 8 x USB 3.0, 4 x COM RS-232/422/485 (ESD 8KV), 32 Isolated DIO
Storage 2 x Front-access 2.5″ SSD/HDD Tray, 1 x CFast Socket, 1 x M.2 Key M
Expansion 2 x mPCIe
Operative range Depends On CPU
Power 6V to 36V DC Power Input with 80V Surge Protection, Configurable Ignition Power Control
