General Features

– Intel® Core™ i7/i5/i3 U-series SoC (Kaby Lake/Skylake)
– 3 Independent GigE LAN with 2 IEEE 802.3at PoE+
– Rugged, Fanless -40°C to 70°C Operating Temperature
– 4 USB 3.0, 2 SATA III, 2 Mini PCIe
– 2 COM RS-232/422/485 with 1 Isolated COM
– 32 GPIO, Ignition Power Control
– Mounting : DIN Rail, Wallmount
– Supports DVI-I and DVI-D dual HD displays
– 6V to 36V DC-in with 80V Surge Protection
– External SIM Socket for WiFi/4G/3G/LTE/GPRS/UMTS

Technical Features
SYSTEM
Processor Intel® Core™ i7-7600U/i7-6600U/i5-6300U/Celeron® 3955U Processor (Kaby Lake-U/Skylake-U)
Chipset Intel® SoC
BIOS AMI
SIO IT8786E
Memory 2 DDR4 2133MHz SO-DIMM, up to 32GB
I/O INTERFACE
Serial 1 Isolated COM RS-232/422/485 (2.5kV Isolation)
1 COM RS-232/422/485
USB 4 USB 3.0 (External)
GPIO 32 GPIO
LED Power, HDD, PoE, Wireless
SIM Card 1 SIM Card Socket (External)
EXPANSION
Mini PCIe 2 Mini PCIe Socket :
1 Full-size for PCIe/USB/External SIM Card/mSATA
1 Full-size for PCIe/USB/mSATA
GRAPHICS
Graphics Processor Intel® HD Graphics 620/520
Interface DVI-I : Up to 1920 x1200 @ 60Hz
DVI-D : Up to 1920 x 1200 @ 60Hz
STORAGE
SATA 2 SATA III support S/W RAID 0, 1 :
1 SATA III (6Gbps)
1 SATA III co-lay with Mini PCIe (6Gbps)
mSATA 1 SATA III co-lay with SATA (Mini PCIe Type, 6Gbps)
Storage Device 1 CFast Socket, Push-in/Push-out Ejector
2x 2.5″SSD/HDD Bracket (Internal)
AUDIO
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
ETHERNET
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
PoE
LAN 2 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210 with Power On/Off Control
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210 with Power On/Off Control
POWER
Power Input 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin terminal block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
OTHERS
TPM Optional Infineon SLB9665 supports TPM 2.0, LPC Interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when CPU overheats.
SOFTWARE SUPPORT
OS Windows 10, Windows 8.1, Windows 7, Linux
MECHANICAL
Dimensions (W x L x H) 186mm x 147mm x 54mm (7.3″ x 5.8″ x 2.1″)
Weight 1.8 kg (3.97 lb)
Mounting Wallmount by mounting bracket
DIN Rail Mount (optional)
ENVIRONMENT
Operating Temperature -40°C to 70°C (-40°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% @ 70°C
Shock IEC 60068-2-27
SSD : 50G @ wallmount, Half-sine, 11ms
Vibration IEC 60068-2-64
SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
