Download Datasheet SH960-CM236/QM170
For requests regarding drivers, documentation and application notes, contact technical support,
Request Information
General Features
CPU 6th Generation Intel® CoreTM Processors, BGA 1440
Chipset Intel® QM170
RAM Two 260-pin SODIMM up to 16GB Dual Channel DDR4 2133MHz
LAN 1 x GigE LAN
I/O 4 x USB 3.0, 8 x USB 2.0, 1 x 8-bit DIO
Storage 4 x SATA (6 Gb/s)
Expansion 1 x PCIe x 16, 8 x PCIe x1
Operative range 0°C – 60°C
