General Features
CPU Socket LGA 1151 for Intel® Core™ i7/i5/i3/Celeron
Chipset Intel® Q370
RAM Supports Dual Channel DDR4 Long-DIMM 2400/2666, up to 64GB
LAN 2 x GigE RJ45
I/O 6 x USB 3.1, 6 x USB 2.0, 6 x SATA3, 10 x COM, 8 x GPI, 8 x GPO
Storage 6 x SATA (6 Gb/s), 1 x M.2 Key M
Expansion 1 x PCIe x16, 1 x PCIe x8, 3 x PCIe x4, 2 xPCIe x1, 1 x mPCIe, 1 x M.2 Key E
Operative range 0°C – 60°C
Power ATX
