ViPAC-816P/R/G(H)
Download Datasheet ViPAC-816P/R/G(H)
For requests regarding drivers, documentation and application notes, contact technical support, support@tpole.it
Request Information
General Features
| CPU | Onboard Intel Celeron N2930 |
|---|---|
| Chipset | – |
| RAM | 2 x 204-pin DDR3L SO-DIMM up to 8GB |
| LAN | 2 x GigE RJ45 |
| I/O | 4 x USB 3.0, 1 x COM (RS232/422/485), 1 x COM (RS232), 1 x COM (RS422/485) |
| Storage | 1 x SATA (6 Gb/s) |
| Expansion | 2 x mPCIe, 1 x PCIe x1, 1 x PCI |
| Display Size and Form Factor | 15.6″, 16:9 |
| Resolution | 1366 x 768 px |
| Brightness | 300 cd/m2, 1000 cd/m2 (H) |
| Touch | PCAP (P), Resistive (R) |
| Mechanicals | IP66 Aluminium Front Bezel, Panel Mount |
| Operating Temperature | 0°C to 50°C |
| Power | 9-36V DC |
| Notes | – |
