Download Datasheet ECS-9771
For requests regarding drivers, documentation and application notes, contact technical support,
Request Information
General Features
CPU Intel® Xeon® E3-1505M v5/Core™ i7-6820EQ/i5-6440EQ Processor (Skylake-H)
Chipset Intel® CM236
RAM 2 DDR4 2133MHz SO-DIMM, up to 32GB (ECC/Non-ECC)
LAN 4-port 10 GigE SFP+, 6 Independent GigE LAN with 4 IEEE 802.3at PoE+
I/O 6 USB 3.0, 4 COM RS-232/422/485 (ESD 8KV), 32 Isolated DIO
Storage 2 2.5″ SSD Tray, 1 CFast Socket
Expansion 4 Mini PCIe
Operative range -40°C to 55°C
Power 6V to 36V DC-in with 80V Surge Protection, Configurable Ignition Power Control
