General Features
CPU 7th Gen. Intel® Core™ i7/i5/i3 Processor
Chipset Intel® H170
RAM 2 x 260-pin DDR4 SO-DIMM memory, up to 32GB
LAN 2 x GigE RJ45
I/O 4 x USB 3.0, 2 x USB 2.0, 1 x COM (RS232/422/485), 1 x COM (RS422/485), 2 x COM (RS232), 4 x DI, 4 x DO
Storage 2 x SATA (6 Gbps)
Expansion 1 x PCIe x16, 1 x PCIe x4, 1 x PCIe x1, 2 x mPCIe
Operative range Depends On CPU
Power 9-36V DC Input
Notes 4 x PCI (Optional)
