Caratteristiche Tecniche
| CPU | 13/12th Gen Intel® Core Processors |
|---|---|
| Chipset | Intel® R680E |
| RAM | Four 288-pin UDIMM up to 128GB (ECC/Non-ECC); Dual Channel DDR5 up to 4400 MHz |
| LAN | 3 x 2.5GbE (RJ-45), 1 x 1GbE (RJ-45, opt. 2.5GbE) |
| I/O | 4 x USB 3.2 Gen 2, 4 x USB 3.2 Gen 1, 2 x RS-232/422/485, 4 x RS-232, 1 x 8-bit DIO, 2 x USB 3.2 Gen1, 1 x USB 2.0 Type A, 2 x USB 2.0 (colay vertical Type A, MOQ required) |
| Storage | 1 x M.2 M key (PCIe x4 Gen4 NVMe, SATA), 4 x SATA 3.0 (up to 6Gb/s) RAID 0/1/5/10 |
| Expansion | 2 x PCIe x16 (Gen 4, 16 or 8+8), 3 x PCIe x4 (Gen 4), 1 x PCIe x4 (Gen 3, co-lay M.2-M2, function selected by BIOS.), 1 x PCI, 1 x M.2 E key, 1 x M.2 A key (support M2-OOB), 1 x M.2 M key (opt. co-lay PCIe x4 Gen3 slot #6, function selected by BIOS.) |
| Operative range | -5 ~ 65°C |
| Power | 8-pin ATX 12V power 24-pin ATX power |
| Notes | CE, FCC Class B, RoHS, UKCA |
