Caratteristiche generali
CPU Single Socket P LGA 3647 Supports Intel® Xeon® W-3200 Processors
Chipset Intel® C621
RAM Six Channel, 8 DIMMs, DDR4, Intel® Optane™ DC Persistent Memory in memory mode (Cascade Lake only)
LAN 2 x 10GigE RJ45, 1 x IPMI
I/O 1 x USB 3.1, 5 x USB 3.0, 2 x USB 2.0
Storage 12 x SATA3 (8 ports from 2x MiniSAS-HD, 2 port by SATA Conn, 2 x M.2)
Expansion (3+1) x PCIe3.0 x16, 3 x PCIe3.0 x8
Operative range
Power ATX
Notes Up to 64 PCIe 3.0 lines using Intel® Xeon® W-3200 processors
