Caratteristiche Tecniche
| CPU | Intel® Core™ Ultra 7/5 Processors, TDP up to 28W |
|---|---|
| Chipset | SoC |
| RAM | Two 262-Pin DDR5-5600 SO-DIMM up to 96GB |
| LAN | 2 x Intel® I226V (10/100/1000/2500Mbps) |
| I/O | 3 x USB 3.2; 1 x USB Type C; 2 x RS-232/422/485; 1 x USB 2.0 (1.0mm pitch); 2 x RS-232 (1.0mm pitch); 1 x HDMI 1.4b: resolution up to 4096×2160@24Hz; 1 x LVDS: dual channel 24-bit, resolution up to 1920×1200@60Hz; 1 x USB-C DP Alt. mode: resolution up to 4096×2304@60Hz; 1 x 8-bit DIO |
| Storage | |
| Expansion | 1 x M.2 M key 2280 (PCIe Gen4 x4); 1 x M.2 B key 3052(USB 3.0/2.0, PCIe x1, SATA); 1 x M.2 E key 2230 (USB 2.0/PCIe x1); 1 x SIM slot for 4G/5G |
| Operative range | -5° ÷ 65° C |
| Power | Wide Range 9÷36V DC |
| Notes | CE, FCC Class B, RoHS |
