Caratteristiche generali

– Intel® Atom™ N4200 & Pentium™ and Celeron™ N Series Processors
‧ Supports Dual Channel DDR3L 1866 non-ECC up to 8GB
‧ 32G EMMC (optional)
‧ 1 x HDMI, 1 x Displayport, 1 x eDP, 1 x LVDS, 1 x VGA
‧ 2 xUSB 3.0, 8 x USB 2.0, 2 x SATA3, 2 x COM
‧ 5 x PCIe x1, 1 x PCIe x4 Slot + 1 PCIE x 1 (Optional), 1 x PCIe x1 (Giga Lan)
‧ 1 x Intel LAN i210IT, 1 x Intel LAN i210AT
‧ 1 x TPM Header
‧ ATX (Vin 4.75-20V, Vsb 4.75-5.25V)
‧ AT (Vin 4.75-20V)

Caratteristiche Tecniche
PROCESSOR SYSTEM
Dimensions COM Express (3.74-in x 3.74-in)
CPU BGA1296 for Intel® Apollo Lake SoC
Chipset N/A
EXSPANSION SLOT
PCIe 6 x PCIe x1 Lane
Mini-PCIe N/A
M.2 N/A
mSATA N/A
MEMORY
Technology Dual Channel DDR3L 1866 MHz
Max 8GB
Socket 2 x SO-DIMM
GRAPHICS
Controller Intel® Gen9 Graphics DX 11/12, OGL4.3/4.4, support 2x DDI, 1x eDP
VGA N/A
DVI N/A
LVDS N/A
HDMI N/A
Multi Display Triple Display
Interface 10/100/1000 Mbps
Controller 1 x Intel® I210IT 1 x Intel® I210AT
REAR I/O
VGA N/A
DVI N/A
HDMI N/A
DisplayPort N/A
Ethernet N/A
USB N/A
Audio jack N/A
Serial N/A
PS2 N/A
INTERNAL CONNECTOR
USB 2 x USB 3.0/ 8 x USB2.0
LVDS N/A
eDP N/A
VGA N/A
Serial 2(RX/TX only)
SATA 2 x SATA3 (6.0 Gb/s)
Parallel N/A
GPIO 4 x GPI + 4 x GPO
SATA PWR Output Con N/A
Speaker Header N/A
TPM Optional TPM2.0
WATCHDOG TIMER
Output From SoC to drag resetion
Interval 0 ~ 255 sec
ENVIROMENT
Operating Temperature 0ºC – 60ºC
Storage Temperature -40ºC – 85° C
