Caratteristiche generali

-6 cores 8th Generation Intel®Xeon®/Core™ i7/i5/i3 (Coffee Lake)
with workstation-grade Intel®C246 Chipset
-4 DDR4 2666MHz Memory, up to 128GB (ECC/Non-ECC)
-6 external USB 3.1 Gen 2 support up to 10Gbps data transfer
-NVIDIA®Tesla®/Quadro®/GeForce®graphics card, powered by
advanced NVIDIA Turing/Pascal architecture, delivers leading AI computing productivity
-Multiple DVI, HDMI and DisplayPort display interfaces support
max 7 independent displays, up to 8K Resolution
-2 Independent GigE LAN, iAMT 12.0 supported
-2 External SIM Socket for WiFi/4G/3G/LTE/GPRS/UMTS
-4 Front-access 2.5″ SSD Tray, RAID 0, 1, 5, 10 supported
-32 Isolated DIO, 4 COM RS-232/422/485
-2 PCI/PCIe Slot, 2 M.2 Socket : 1 M.2 Key M, 1 M.2 Key E
-System-oriented power optimization, up to 300Windependent graphics card
-Supports wide range power input with 80V Surge Protection
-Configurable Ignition Power Control

Caratteristiche Tecniche
SYSTEM
Processor 6 cores Intel® Xeon®/Core™ i7/i5/i3 Processor (Coffee Lake-S)
Chipset Intel®C246
BIOS AMI
SIO IT8786E
Memory 4 DDR4 2666MHz SO-DIMM, up to 128GB (ECC/Non-ECC)
OS Windows 10, Linux
I/O INTERFACE
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB – 6 USB 3.1 Gen 2 (External)
– 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless
SIM Card 2 External SIM Card Socket
EXPANSION
Mini PCIe 2 Full-size for PCIe/USB/External SIM Card/mSATA
M.2 1 M.2 Key E Socket
PCIe 1 PCIe x4,1 PCIe x1
GRAPHICS
Graphics Processor Intel®UHD Graphics P630/630
Independent Graphics : By request
Interface Up to 7 independent displays :
– 1 DVI : Up to 1920 x 1200 @60Hz
– 1 DisplayPort : Up to 4096 x 2304 @60Hz
– 1 Digital Display : Up to 4096 x 2304 @60Hz
– By requested Graphics Car
STORAGE
SATA 4 SATA III (6Gbps) support S/W RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
Storage Device – 4 Front-access 2.5″SSD/HDD Tray
– 1 M.2 Key M Socket
AUDIO
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
ETHERNET
LAN 1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN 2 Intel® I210 GigE LAN
POWER
Power Input – 24V to 36V, DC-in -12V DC-in (Optional)
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block
Surge Protection Up to 80V/1ms Transient Power
OTHERS
TPM Optional Infineon SLB9665 supports TPM 2.0, LPC Interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Mgmt. Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when CPU overheats.
MECHANICAL
Dimensions 330.0mm x 210.0mm x 172.0mm (12.99″ x 8.27″ x 6.77″)
Weight (w/o Graphics Card) RCX-1400FR PEG : 5.6 kg (12.37lb)
RCX-1400F PEG : 5.4 kg (11.87 lb)
Mounting Wallmount by mounting bracket
ENVINROMENT
Operating Temp. -25°C to 45°C (-13°F to 113°F)
Storage Temp. -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% @ 45°C
Shock/Vibration – IEC 61373 : 2010
– Railway Applications : Rolling Stock Equipment, Shock and
Vibration Tests
EMC CE, FCC, EN50155, EN50121-3-2

Contattaci per maggiori informazioni su GPU Computing Systems RCX-1430FR PEG
