Box PC Fanless

Quad Core Intel® Xeon®/Core™ i7/i5/i3, Intel® C236, 2 DDR4 2133MHz up to 32GB, 6 LAN, 4 COM, 8 USB 3.0, 1 USB 2.0, 32 Isolated DIO, 3 Mini PCIe Socket, 2-port CAN 2.0 A/B

Caratteristiche generali
  • Quad Core Intel® Xeon®/Core™ i7/i5/i3
  • Intel® C236
  • 2 DDR4 2133MHz up to 32GB
  • 2 LAN, 4 LAN PoE+ X-coded M12, 4 COM, 8 USB 3.0, 1 USB 2.0, 32 Isolated DIO, 3 Mini PCIe Socket, 2-port CAN 2.0 A/B
Caratteristiche Tecniche


Processor Quad Core Intel® Xeon®/Core™ i7/i5/i3 Processor (Skylake-S/Kaby Lake-S)
Chipset Intel® C236
Memory 2 DDR4 2133MHz SO-DIMM, up to 32GB (ECC/Non-ECC)
OS Windows 10, Windows 8.1, Windows 7, Linux
I/O Interface
Serial 4 COM RS-232/ 422/ 485 (ESD 8KV)
USB 8 USB 3.0 (4 Front, 4 Rear)
1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless, PoE
SIM Card 3 External SIM Card Socket (1 for CAN Bus, Optional)
CAN Bus 2-port CAN 2.0 A/B
Mini PCIe 3 Full-size for PCIe/ USB/ External SIM Card/ mSATA
Processor Intel® HD Graphics 630/530
Interface DVI-I : Up to 1920 x 1200 @ 60Hz
DVI-D : Up to 1920 x 1200 @ 60Hz
DisplayPort : Up to 4096 x 2304 @ 60Hz
SATA 4 SATA III (6Gbps) support S/W RAID 0, 1, 5, 10
mSATA 3 SATA III (Mini PCIe Type, 6Gbps, Optional)
M2DOM 1 PCIe 3.0 (8GT/s)
Storage Device 1 CFast Socket, Push-in/ Push-out Ejector
4 Front-access 2.5″ SSD/ HDD Tray
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
PoE (X-coded M12)
LAN 3 to LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210 with Power On/Off Control
Power Input 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block
Surge Protection Up to 80V/1ms Transient Power
TPM Optional Infineon SLB9665 supports TPM 2.0, LPC Interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Dimensions (WxLxH) 260mm x 215mm x 79mm (10.2″ x 8.5″ x 3.1″)
Weight 4.5 kg (9.92 lb)
Mounting Wallmount by mounting bracket
DIN Rail Mount (Optional)
2U Rackmount (Optional)
Operating Temp. 35W TDP CPU :
Core™ i7, i5, i3 : -40°C to 75°C (-40°F to 167°F)
Xeon® E3-1268L v5 : -40°C to 70°C (-40°F to 158°F)
Core™ i7, i5, i3 : -40°C to 55°C (-40°F to 131°F)
Xeon® E3-1275 v6, E3-1275 v5, E3-1225 v5 : -40°C to
45°C (-40°F to 113°F)
Storage Temp. -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% @ 75°C
Shock IEC 60068-2-27
SSD : 50G @ wallmount, Half-sine, 11ms
Vibration IEC 60068-2-64
SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
