Caratteristiche generali
  • Intel Celeron N2930 Processor
  • SUS 316 Stainless Steel
  • Total IP66 Grade with M12 Waterproof Connector
  • Variety of IO applications
  • WLAN for Option
  • Wide range DC 9~36V Power Input
  • Support Panel Mount & VESA Mount
  • Fanless Design
  • ATEX Zone2, IECEx and C1D2 Certified
Caratteristiche Tecniche
CPU Onboard Intel Celeron N2930 Processor (2M Cache,1.83GHz)
System Chipset SoC
Memory Onboard 4GB DDR3L SDRAM
Onboard 8GB DDR3L SDRAM (optinon)
USB 1 x M12 8-pin for 2 x USB 2.0 with waterproof cover and chain
Serial/Parallel 1 x M12 8-pin for COM1, RS-232/422/485, default RS-232, with waterproof cover and chain
Graph 1 x M12 12-pin for VGA with waterproof cover and chain
LAN 2 x M12 8-pin for LAN with waterproof cover and chain
Power 1 x M12 3-pin for DC power with waterproof cover and chain
Storage 1 x SATA 2,5″ HDD Space
movable device 1 x internal SD card slot onboard
Expansion slot 1 x Mini-PCIe slot (full size) for option WLAN/BT module
Power Input DC 9-36V
Power Consumption MAX: 15.9W
Construction 316 Stainless Steel Chassis
Mounting VESA mount 100 x 100, Wall mount
IP Rating Total IP66
Dimensions 334 x 195 x 38.5mm
Net Weight 4.0 kg
Operating Temperature -20~ 60°C
Storage Temperature -30~ 70°C
Storage Humidity 10 to 90%@ 40°C, non-condensing
Certifcate CE / FCC Class A
ATEX Zone2 Ex nA IIC T4 Gc
Class I, Division 2, Group ABCD T4
ANSI/ISA 12.12.01-2013
CSA Std. C22.2 No213-1987
Windows 7 Pro for Embedded
Windows Embedded Standard 7
Windows Embedded 8.1 Industry Pro
Windows Embedded 8 Standard
Windows 10 IoT ENT LTSB

Contattaci per maggiori informazioni su AEx-2410
