PTH171/PTH173
Richiedi informazioni
Caratteristiche Tecniche
| CPU | Intel® Panther Lake H processor, TDP up to 25W; Intel® Core™ Ultra 9 388H (H484-12XeET, vPro); Intel® Core™ Ultra 7 368H (H484-12XeET, vPro); Intel® Core™ Ultra 7 358H (H484-12XeET); Intel® Core™ Ultra 5 338H (H484-12XeET, vPro); Intel® Core™ Ultra 9 386H (H484-4XeET, vPro); Intel® Core™ Ultra 7 366H (H484-4XeET, vPro); Intel® Core™ Ultra 7 356H (484-4XeET); Intel® Core™ Ultra 5 336H (444-4XeET, vPro); Intel® Core™ Ultra 7 365 (404-4XeET, vPro); Intel® Core™ Ultra 7 355 (404-4XeET); Intel® Core™ Ultra 5 335 (404-4XeET, vPro); Intel® Core™ Ultra 5 325 (404-4XeET) |
|---|---|
| Chipset | – |
| RAM | 2x 262-pin SODIMM up to 128GB Dual-channel SODIMM DDR5 up to 6400 MHz (H404) / 7200 MHz (H484) |
| LAN | LAN1/2: i226V/IT (10/100/1000/2.5G speeds); LAN3(vPro): i226LM/IT (10/100/1000/2.5G speeds) |
| I/O |
4 x USB 3.2 Gen2 Type A; 1 x USB 3.2 Gen 2 Type C (DP alt-mode/USB3.2 Gen 2/PD 15W); 1 x USB 2.0 Type A; 4 x USB 2.0 (2.0mm pitch); 2 x RS-232/422/485 (2.0mm pitch); 1 x RS-232 with power (2.0mm pitch); 1 x RS-232 (2.0mm pitch) colay with DIO-4bit or PS/2 (Option); 1 x HDMI (resolution up to 4096×2160 @60Hz); 1 x DP++ (resolution up to 4096×2304 @60Hz); 1 X USB Type C (DP alt-mode/USB3.2 Gen2/PD 15W) resolution up to 4096×2304 @60Hz (HBR2); 1 x M.2 A key, support M2A-Display ( eDP / LVDS / VGA / DP / HDMI or DVI via optional cable); 1 x 8-bit DIO; 1 x SMBus |
| Storage | 2 x SATA 3.0 H484 RAID 0,1,5 supported by Intel VMD H404 RAID 0,1 (shared with M.2 M key) |
| Expansion | 1 x M.2 2242/2280 M Key (PCIE Gen4x4, SATA3 opt. selected by BIOS, support NVMe ); 1 x M.2 2242/3042/3052 B Key (PCIE Gen4x1 shared with M.2 A key by request, USB3.2 Gen2, USB2.0, SIM); 1 x M.2 2230 E Key (PCIE Gen4x1 and USB2.0, support Intel® CNVi,WIFI7); 1 x M.2 2230 E Key (PCIE Gen4x1 and USB2.0, support Intel® CNVi,WIFI7); 1 x PCIe Gen 5 x4 slot |
| Operative range | -5° ÷ 65° C |
| Power | Single 12VDC for PTH171; Wide Range 12÷28VDC for PTH173 |
| Notes | CE, FCC Class B, RoHS, UKCA |
