Caratteristiche Tecniche
| CPU | AMD® Ryzen™ Embedded R1606G AMD® Ryzen™ Embedded R1505G, 12W AMD® Ryzen™ Embedded R1305G, AMD® Ryzen™ Embedded R1102G |
|---|---|
| Chipset | – |
| RAM | DDR4 Memory Down up to 4GB/8GB Single Channel DDR4 2400MHz |
| LAN | 1 x Intel® I211AT PCIe (10/100/1000Mbps) or 1 x Intel® I210IT PCIe (10/100/1000Mbps) (available upon request) |
| I/O | 1 x 8-bit DIO |
| Storage | 16/32/64GB Emmc |
| Expansion | 1 x Full-size Mini PCIe (PCIe Gen2/USB 2.0, opt: USB 3.1 Gen2/USB 2.0) |
| Operative range | 0 ÷ 60°C (-20 ÷ 70°C opt.) |
| Power | Single 12V +/-5% DC |
| Notes | – |
