Caratteristiche Tecniche
| CPU | MediaTek Genio 1200 Processor with Quad-core Cortex-A78 @2.2GHz and Quad Cortex-A55 @2.2GHz |
|---|---|
| Chipset | – |
| RAM | 8GB LPDDR4X SDRAM |
| LAN | 2 x 10/100/1000 Mbps Ethernet LAN by Microchip LAN7800 |
| I/O | 2 x USB 3.0, 1 x Micro USB 2.0 OTG Port, 1 x Micro USB 2.0 Debug Port, 1 x COM RS-232/422/485, 2 x RS-232 Header, 1 x USB 2.0 Header, 1 x GPIO Connector |
| Storage | 64GB eMMC, 1 x Micro SD Slot |
| Expansion | 1 x M.2 Key B Socket (2280),1 x M.2 Key E Socket (2230), 1 x Mini PCIe Socket for PCIe/USB 2.0/SIM Card, 2 x Mini PCIe Socket for PCIe |
| Operative range | -20°C to 85°C |
| Power | 12V DC-in |
| Notes | – |
