Caratteristiche Tecniche
| CPU | 13th Generation Intel® LGA 1700 Socket Processors, TDP support up to 125W |
|---|---|
| Chipset | Intel® R680E/Q670E |
| RAM | Four 288-pin UDIMM up to 128GB, DDR4 3200MHz |
| LAN | 1 x Intel® I226-LM PCIe (10M/100M/1000Mbps/2.5G) (only Xeon, Core i9/i7/i5 support iAMT), 1 x Intel® I226-V PCIe (10M/100M/1000Mbps/2.5G), 2 x Intel® x550-AT2 (10 GBASE-T/1 GbE/100 Mbps)(R680E only, no support WOL) |
| I/O | 4 x USB 3.2 Gen2, 4 x USB 3.2 Gen1, 2 x RS-232/422/485, 4 x RS-232 |
| Storage | 4 x SATA 3.0, 1 x M.2 2230 Key M |
| Expansion | 1 x PCIe x16 (Gen 5), 4 x PCIe x4 (Gen 4), 2 x PCI, 1 x M.2 2242/2260/2280 M key, 1 x M.2 2242/2260/2280 M key |
| Operative range | -5°C to 65°C |
| Power | ATX |
| Notes | – |
