ADS103-R680/Q670
Richiedi informazioni
Caratteristiche Tecniche
| CPU | 14/13/12th Gen Intel® LGA 1700 Socket Processors |
|---|---|
| Chipset | Intel® R680E/Q670E |
| RAM | Two 260-pin SODIMM up to 64GB |
| LAN | 1 x Intel® I226LM PCIe (10/100/1000/2.5G), 1 x Intel® I219LM PHY (10/100/1000), (Opzionale 1 x Intel® I210AT PCIe(10/100/1000)) |
| I/O | 4 x USB 3.2 Gen2, (Opzionale 6 x USB 3.2 Gen2), 4 x USB 2.0 (Internal), 2 x COM (RS232/422/485), 1 x DP++, 1 x DP++/HDMI (Opzionale 1 x estensione display DFI per (DP/HDMI/VGA)) |
| Storage | 2 x SATA 3 |
| Expansion | 1 x PCIe x16 (Gen 5), 1 x M.2 2230 E Key (USB/PCIe x1), 1 x M.2 2242/3042/3052 B Key (PCIe Gen3 x1/SATA/USB 3.2 Gen2/USB 2.0) |
| Operative range | -5°C to 65°C |
| Power | Wide Range 15~36V |
| Notes | CE, FCC Classe B, RoHS |
