AiTRON-912EP/H
Richiedi informazioni
Caratteristiche Tecniche
| CPU |
Intel Core Ultra 5 125U (2 P-Cores x 1.3GHz, 8 E-Cores x 0.8GHz,12MB cache, 15W) Intel Core Ultra 7 155U (2 P-Cores x 1.7GHz, 8 E-Cores x 1.2GHz,12MB cache, 15W) |
|---|---|
| Chipset | Intel SoC |
| RAM | 1 x DDR5-5600MHz SO-DIMM, up to 32GB |
| LAN | 2 x RJ-45, support Intel I226V/IT 2.5GbE LAN |
| I/O |
4 x USB 3.2 Gen1 Type-A; 1 x HDMI 2.1, resolution up to 7680×4320@60 Hz; 1 x DP 1.4, resolution up to 7680×4320@60Hz; 1 x DB9, supports RS-232/422/485 (COM1, BIOS selection, RS-232 is default) 1 x DB9, supports RS-232/422/485 (COM2, BIOS selection, RS-232 is default), optional 1 x DB9, supports RS-232(COM3), optional |
| Storage | 1 x M.2 2280 M-Key socket (PCle 3.0 x4) |
| Expansion |
1 x M.2 2230 E-Key (USB2.0, PCIe x1) for optional Wi-Fi/BT module 1 x M.2 3402/3052 B-key (PCIe x1, USB3.2 Gen1, USB2.0) for optional LTE/5G module 1 x Nano-SIM slot |
| Display Size and Form Factor | 12.1″ TFT-LCD |
| Resolution | 1024 x 768 px |
| Brightness | 350 cd/m2 |
| Touch | Projected Capacitive Touch |
| Mechanicals | Aluminum Die-casting Chassis; Panel Mount, VESA 100 x 100; IP66 Compliant Front Bezel |
| Operating Temperature | -20°÷60°C |
| Power | 9÷36V DC |
| Notes | CE/FCC Class A |
