Caratteristiche generali

-Quad Core Intel Atom® x7-E3950 SoC (Apollo Lake-I) supports lower power consumption
-Fanless, -40°C to 85°C Operating Temperature
-Supports HDMI & VGA Dual Display, up to 4K resolution
-DDR3L 1866MHz memory supports up to 8GB
-2 GigE LAN support IEEE 1588 (PTP)
-4 COM RS-232/422/485 with 2 Isolated
-16 Isolated DIO, 6 USB, 1 SIM Socket
-3 Mini PCIe, 1 SATA III, 1 M.2
-SIM Socket for WiFi/4G/3G/LTE/GPRS/UMTS
-9V to 36V wide range DC Power Input
-TPM 2.0 supported

Caratteristiche Tecniche
SYSTEM
Processor Intel Atom® x7-E3950 processor (Apollo Lake-I)
BIOS AMI
SIO IT8786E
Memory 1 DDR3L 1866MHz SO-DIMM, up to 8GB
OS Windows 10
Linux
I/O INTERFACE
Serial 4 COM RS-232/422/485 with 2 Isolated
USB 2 USB 3.0 (External)
USB 2.0 (2 External, 2 Internal)
DIO 16 Isolated DIO : 8 DI, 8 DO
LED Power
HDD
Wireless
SIM card 1 Internal SIM socket
EXPANSION
3 Mini PCIe sockets 1 Mini PCIe for PCIe/USB/SIM card
1 Mini PCIe for PCIe/USB/Optional mSATA
1 Mini PCIe for PCIe/USB
M.2 1 M.2 Key B socket
GRAPHICS
Processor Intel® HD graphics 505
Interface HDMI : Up to 3840 x 2160 @30Hz
VGA : Up to 1920 x 1440 @60Hz
STORAGE
SATA 1 SATA III (6Gbps)
mSATA 1 SATA III (Mini PCIe type, 6Gbps)
Storage Device 1 2.5″ SSD/HDD bracket (Internal)
AUDIO
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in
1 Line-out
ETHERNET
LAN 1 Intel® I210 GigE LAN supports IEEE 1588
LAN 2 Intel® I210 GigE LAN supports IEEE 1588
POWER
Power Input 9V to 36V DC power input
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Remote Switch 2-pin Terminal Block
OTHERS
TPM Optional Infineon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
HW Monitor Monitoring temperature, voltages. Auto throttling control when CPU overheats.
MECHANICAL
Dimension 155mm x 111mm x 68mm (6.1″ x 4.4″ x 2.7″)
Weight 1.1 kg (2.43 lb)
Mounting Wallmount by mounting bracket
DIN Rail mount (Optional)
2U Rackmount (Optional)
ENVIRONMENT
Operating Temperature -40°C to 85°C (-40°F to 185°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% @ 85°C
EMC CE, FCC, EN50155, EN50121-3-2

Contattaci per maggiori informazioni su Ultra-Compact Systems SPC-4020A
