Caratteristiche generali
  • 8 Cores 9th Generation Intel®Xeon®/Core™ i7/i5/i3 (Coffee LakeRefresh) with workstation-grade Intel®246 Chipset
  • 4 DDR4 2666MHz Memory, up to 128GB (ECC/Non-ECC)
  • 6 ports external USB 3.1 Gen 2 support up to 10Gbps data transfer
  • Rugged & Fanless design, -40°C to 75°C Operating Temperature
  • 2 External SIM Socket for WiFi/4G/3G/LTE/GPRS/UMTS
  • 4 Front-access 2.5″ SSD Tray, RAID 0, 1, 5, 10 supported
  • 4 PCIe Slot : 1 PCIe x8, 3 PCIe x4
  • Supports max 300W Power Budget for independent graphics operation
  • 32 Isolated DIO, 6 USB 3.1, 4 COM RS-232/422/485
  • 2 M.2 Socket : 1 M.2 Key M, 1 M.2 Key E
  • 6V to 36V DC Power Input with 80V Surge Protection
  • Configurable Ignition Power Control
Caratteristiche Tecniche
Processor Intel®Xeon®/Core™ i7/i5/i3 Processor (CFL-R S/CFL-S)
Chipset Intel® C246
Memory 4 DDR4 2666MHz SO-DIMM up to 128GB (ECC/Non-ECC)
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB 6 USB 3.1 Gen 2 (External)
Isolated DIO 32 Isolated DIO : 16 DI 16 DO
LED Power, HDD, Wireless
SIM Card 2 External SIM Card Socket
Mini PCIe 2 Full-size for PCIe/USB/External SIM Card/mSATA
M.2 1 M.2 Key E Socket
PCIe 1 PCIe x8, 3 PCIe x4
Graphics Processor Intel® UHD Graphics P630/630
Interface 1 DVI-I : Up to 1920 x 1200 @ 60Hz
SATA 4 SATA III (6Gbps) support S/W RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe Type 6Gbps)
Storage Device 4 Front-access 2.5″ SSD/HDD Tray
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
LAN 1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN 2 Intel® I210 GigE LAN
Power Input 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block
Surge Protection Up to 80V/1ms Transient Power
TPM Optional Infineon SLB9665 supports TPM 2.0, LPC Interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when CPU overheats.
OS Windows 10, Linux
Dimensions 250.4mm x 210.0mm x 172.0mm (9.86″ x 8.27″ x 6.77″)
Weight 5.0 kg (11.0 lb)
Mounting Wallmount by mounting bracket
Operating Temperature 35W TDP CPU : -40°C to 75°C (-40°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% @ 75°C
Shock IEC 60068-2-27
Vibration IEC 60068-2-64
EMC CE, FCC, EN50155, EN50121-3-2
