Caratteristiche generali
  • 8 Cores 9th Generation Intel®Xeon®/Core™ i7/i5/i3 (Coffee LakeRefresh) with workstation-grade Intel®246 Chipset
  • 4 DDR4 2666MHz Memory, up to 128GB (ECC/Non-ECC)
  • 6 ports external USB 3.1 Gen 2 support up to 10Gbps data transfer
  • Rugged & Fanless design, -40°C to 75°C Operating Temperature
  • 2 External SIM Socket for WiFi/4G/3G/LTE/GPRS/UMTS
  • 4 2.5″ SSD Bracket, RAID 0, 1, 5, 10 supported
  • 1 PCIe x16 Slot, 1 PCI Slot
  • Supports max 300W Power Budget for independent graphics operation
  • 32 Isolated DIO, 6 USB 3.1, 4 COM RS-232/422/485
  • 2 M.2 Socket : 1 M.2 Key M, 1 M.2 Key E
  • 6V to 36V DC Power Input with 80V Surge Protection
  • Configurable Ignition Power Control
Caratteristiche Tecniche
Processor Intel®Xeon®/Core™ i7/i5/i3 Processor (CFL-R S/CFL-S)
Chipset Intel® C246
Memory 2 DDR4 2666MHz SO-DIMM, up to 128GB (ECC/Non-ECC)
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB 6 USB 3.1 (External)
1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO: 16 DI
LED Power, HDD, PoE, Wireless
SIM Card 2 External SIM Card Socket
Mini PCIe 2 Full-size for PCIe/USB/External SIM Card/mSATA
M.2 1 M.2 Key E Socket
PCIe 1 PCIe x16
Graphics Processor Intel® UHD Graphics P630/630
Interface 1 DVI-I: Up to 1920 x 1200 @60Hz
2 DisplayPort : Up to 4096 x 2304 @60Hz
SATA 4 SATA III (6Gbps) support S/W RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
Storage Device 2 2.5” SSD/HDD Bracket (Internal)
1 M.2 Key M Socket (Internal)
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
LAN 1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN 2 Intel® I210 GigE LAN
Power Input 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block
Surge Protection Up to 80V/1ms Transient Power
TPM Optional Infineon SLB9665 supports TPM 2.0, LPC Interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when CPU overheats.
OS Windows10,Linux
Dimensions 250.4mm x 210mm x 131.4mm (9.86″ x 8.27″ x 5.17″)
Weight 4.3 kg (9.5 lb)
Mounting Wallmount by mounting bracket
Operating Temperature 35W TDP CPU : -40°C to 75°C (-4°F to 158°F)
65W TDP CPU : -40°C to 55°C (-4°F to 131°F)
80W TDP CPU : -40°C to 45°C (-4°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% @ 75°C
Shock IEC 60068-2-27
SSD : 50G @ wallmount, Half-sine, 11ms
Vibration IEC 60068-2-64
SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

Contattaci per maggiori informazioni su Expandable Systems RCX-1211
