Caratteristiche generali
CPU 8 Cores 9th Generation Intel® Xeon®/Core™ i7/i5/i3 (Coffee Lake Refresh)
Chipset Intel® C246
RAM 2 DDR4 2666MHz Memory, up to 64GB (ECC/Non-ECC)
LAN 6 Independent GigE LAN with 4 IEEE 802.3at PoE+
I/O 32 Isolated DIO, 3 External SIM Socket, 6 USB 3.1, 4 COM
Storage 4 2.5″ SSD trays, RAID 0, 1, 5, 10 supported, 1 CFast, 1 M.2, 4 SATA III
Expansion 1 PCI, 2 Mini PCIe/mSATA, 1 M.2
Operative range Depends on CPU
Power 12V to 36V DC-in, 80V Surge Protection, Ignition Control
Notes
