Embedded PC GPU Computing Systems

ECX-1200 GTX1050

Solution provider for Embedded and Industrial PC
Caratteristiche generali
  • 8 Cores 9th Generation Intel® Xeon®/Core™ i7/i5/i3 (Coffee Lake Refresh) with workstation-grade Intel® C246 Chipset
  • 2 DDR4 2666MHz Memory, up to 64GB (ECC/Non-ECC)
  • NVIDIA® GeForce® GTX 10 Series graphics engine supports NVIDIA®Pascal™ GPU architecture, up to 8K resolution
  • 1 VGA, 1 HDMI, 2 DVI & 3 DisplayPort interfaces support up to 6 independent HD displays
  • Multiple external USB 3.1 Gen 2 support up to 10Gbps data transfer
  • 6 Independent GigE LAN with 4 IEEE 802.3at PoE+
  • 32 Isolated DIO, 3 External SIM Socket, 2 SSD Tray, 6 USB 3.1, 4 COM
  • 24V to 36V DC-in, 80V Surge Protection, Ignition Control
Caratteristiche Tecniche
SYSTEM
Processor 8 Cores Intel® Xeon®/Core™ i7/i5/i3 Processor (CFL-R S)
Chipset Intel® C246
BIOS AMI
SIO IT8786E
Memory 2 DDR4 2666MHz SO-DIMM, up to 64GB (ECC/Non-ECC)
I/O INTERFACE
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB 6 USB 3.1 (External)
1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO: 16 DI
LED Power, HDD, PoE, Wireless
SIM Card 3 External SIM Card Socket
EXPANSION
Mini PCIe 2 Full-size for PCIe/USB/External SIM Card/mSATA
M.2 1 M.2 Key E Socket
GRAPHICS
Graphics Processor Intel® UHD Graphics P630/630
NVIDIA® GeForce®GTX1050
Interface 1 VGA : Up to 1920 x 1200 @60Hz
1 HDMI : Up to 4096 x 2304 @60Hz
2 DVI-D : Up to 1920 x 1200 @60Hz
1 DisplayPort : Up to 7680 x 3840 @60Hz
2 DisplayPort : Up to 4096 x 2304 @60Hz
STORAGE
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket
1 M.2 Key B Socket
Storage Device 1 CFast Socket, Push-in/Push-out Ejector
2 Front-access 2.5″ SSD/HDD Tray
AUDIO
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
ETHERNET
LAN 1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN 2 Intel® I210 GigE LAN
POE
LAN 3 to 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
POWER
Power Input 12V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block
Surge Protection Up to 80V/1ms Transient Power
OTHERS
TPM Optional Infineon SLB9665 supports TPM 2.0, LPC Interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when CPU overheats.
SOFTWARE SUPPORT
OS Windows10,Linux
MECHANICAL
Dimensions 260mm x 215mm x 79,1mm (10.24″ x 8.46″ x 3.11″)
Weight 5.8 kg (12.79 lb)
Mounting Wallmount by mounting bracket
DIN Rail Mount (Optional)
2U Rackmount (Optional)
ENVINROMENT
Operating Temperature 35W TDP CPU : -20°C to 60°C (-4°F to 140°F)
65W TDP CPU : -20°C to 55°C (-4°F to 131°F)
80W TDP CPU : -20°C to 45°C (-4°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% @ 60°C
Shock IEC 60068-2-27
SSD : 50G @ wallmount, Half-sine, 11ms
Vibration IEC 60068-2-64
SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

Contattaci per maggiori informazioni su GPU Computing Systems ECX-1200 GTX1050
