Caratteristiche Tecniche
CPU | Intel Alder Lake-N Series |
---|---|
Chipset | – |
RAM | 8GB/16GB LPDDR5 5200 Memory down |
LAN | 2 x Intel i226 2.5GbE (support TSN), 1 x Intel Ethernet i210 GbE (support DFI OOB function) |
I/O | 3 x RS232/422/485 DB9 connector + 1 x COM/DIO port, 2 x USB 3.2 type A, 2 x USB-C / 4 x USB 3.2 type A, 1 x VGA + 1 x HDMI |
Storage | 1 x M.2 2280 B+M key (SATA/PCIe), 1 x M.2 2230 A+E key (PCIe), eMMC 32GB/64GB |
Expansion | 1 x M.2 2230 A+E key (USB 2.0/PCIe), 1 x M.2 3042/3052 B key (USB 3.0/PCIe) with SIM, 1 x M.2 2242/2280 B+M key (PCIe/SATA) |
Operative range | 0°C to 65°C |
Power | 9V to 36V |
Notes | Certifications shock, Vibration MIL-STD-810G |
