Caratteristiche Tecniche
| CPU | Intel J6413 Processor, Elkhart Lake Processor |
|---|---|
| Chipset | – |
| RAM | 1 x 260-pin SO-DIMM up to 32GB DDR4 |
| LAN | 1 x GbE ports by RJ-45 with Intel I210-AT, 2 x Gigabit IEEE 802.3af/at (15.4W/30W) PoE ports by RJ-45 with Intel I210-A |
| I/O | 2 x USB 3.1 (Type A) stack port, 2 x USB 2.0 (Type A) stack port, 1 x USB 2.0 (Type A) stack port (internal),1 x RS-485/RS-232/RS-422 (DB9), 1 x RS-232(DB9),1 x 8-bit GPIO |
| Storage | 1 x SATA 3 Connector (7-pin) |
| Expansion | 1 x M.2 B-Key Socket (USB 3.1 / USB 2.0) 3042/3052, 1 x M.2 M-Key Socket (SATA 3) 2242 |
| Operative range | -20~70˚C |
| Power | 24V DC In |
| Notes | – |
